Pressure equipment, pipeline flow meter (shell) belongs to the pressure piping components used in pressure piping systems whose quality directly affects the pressure pipeline safety. Our company manufactured flowmeter (shell) by the third-party supervision and inspection agencies qualified factory safety and quality assurance.

Standard orifice plate flowmeter performance characteristics:

1, can be in a wide range of flow rate accurately measure the flow of gas, liquid and steam without the influence of the physical properties of the fluid; not subject to temperature, pressure, while not easy to plug, not easy to card, not easy to scale, high temperature, high pressure; safe and explosion-proof, suitable for harsh environments;

2, no moving parts, no holes and gaps in the design, no wear and tear, dirt, no mechanical maintenance, long service life; using micro-power consumption of high-tech, battery-powered on-site display type flowmeter, can be uninterrupted operation for more than two years; temperature and pressure compensation of the integrated design; current outputs are galvanic isolation type, has a good ability to inhibit common-mode interference; at the same time show the value of the flow rate and the cumulative value of the flow rate, do not have to take turns switching; Adopt anti-vibration probe, effectively eliminate the influence of external vibration;

The following figure shows:

The use of split signal converter, cable length of 100 meters; range ratio as wide as 20:1, the overall structure of the instrument is well designed, wide dynamic measurement range, pressure loss is small; the meter body is made of stainless steel, can be applied to the measurement of corrosive media; on-site liquid crystal display, pulse, 4 ~ 20mA output or 485 communication, can be connected with industrial automation systems.

Flowmeter is a kind of velocity type instrument to measure the flow of gas medium in closed pipeline, applicable to natural gas and other industrial fields in the accurate measurement of gas quantity. Due to its small size, high accuracy and good repeatability, it is particularly suitable for trade settlement measurement. On its counter is displayed in the field pipeline, the working temperature and working pressure of the gas flow through the volume of the volume, that is, the uncorrected flow rate, the unit m3, can also be displayed as a standard gas pressure under the flow rate (20 ℃, 101.325kpa) of the volume of the volume (Nm3).

The flow meter consists of a sensor and a conversion display. The vortex generator consists of specific spiral-shaped vanes, which are fixed at the front end of the contracted section of the housing and force the fluid to produce a strong vortex flow. The detecting element is installed near the throat of the expanding tube, and the frequency signal of the vortex inlet can be measured with the detecting element such as thermal, piezoelectric, strain, capacitance or fiber optic. Rectifier fixed in the flowmeter meter body outlet, its role is to eliminate the vortex flow, in order to reduce the influence of the downstream flow pattern on the instrument measurement. The casing is designed into a certain shape of the flow channel, so that the vortex formation, fixing and protecting the parts installed inside, and connected to the pipeline through the flange.
